BROSHUIS 1ADU '2008 extended and torsion axle on lease

SPECIAL LOW-LOADER SEMI-TRAILER EXTENDABLE STEERING AXLE BROSHUIS 1ADU / 1A

?Year of manufacture: 2008

?Type: extendible 1x

?Manufacturer: Broshuis - Netherlands

?Color: red

?Vehicle type: Low-bed semi-trailer

?VIN number: XNJ11H5SL08L05516

?Previously registered in: Germany

Vehicle description

Make/Type: Broshuis 1ADU / 1A (TIEFBETT – submersible model)

Condition: Fully inspected, ready to work

Owner: One owner, accident-free vehicle

Registration: Registered in the EU

Purpose:

– Construction machines, loaders, excavators

– Special vehicles, buses

– Mobile homes, boats

– Combine harvesters, containers

The solid frame, extendable construction and hydraulically steered axle ensure maximum versatility and reliability in the most difficult transport conditions.

Technical data:

Parameter Value

Fifth wheel load 18 t

Axle bogie load 10 t

Net weight approx. 8.2 t

Net load capacity approx. 19.8 t

Loading height 330 mm

Platform length 7600 mm

Platform extension 5500 mm

Total extended length 18650 mm

Loading width 2530 mm

Total load capacity approx. 20 t

Standard equipment:

– Extendable frame (1x extension)

– 10T air suspension + Broshuis full hydraulic steering

– Hydraulically steered rear axle

– 245/70 R17.5 tires (Continental, Goodyear or equivalent)

– Fixed gooseneck (height 230 mm)

– Side beams prepared for removable floor

– 28 mm thick hardwood floor

– Tire pressure monitoring system (TPMS, ECE R141)

– Wabco braking system with EBS and automatic brake force regulation

– LED installation (rear, position, reversing, fog lights)

– Electrical connections: Dual 7-pin SAE + NATO 24V

– Lift/lower valves for easier loading

– Automatic steering adjustment and tensioning system (up to 32 bar)

Additional equipment:

– Spare wheel in the holder

– EBS connector

– Palm air connectors

– Load securing rings (2.5T and 13.4T)

– Securing sockets for 20 ft / 30 ft / 40 ft containers (optional)

– Rope hooks on both sides of the trailer

Painting and anti-corrosion protection:

– Frame metalized and painted according to the Broshuis 2K system

– Full anti-corrosion protection after shot-blasting

– Axles painted black for increased resistance

– Reflective markings: white (sides) and red (rear)

Summary:

The Broshuis A:1ADU-28/1 semi-trailer is the perfect solution for carriers who expect:

✅Maximum maneuverability

✅High reliability

✅Long-lasting durability

ADVANTAGES AND APPLICATION

✅Unique steering axle – makes maneuvering much easier and increases safety in difficult road conditions and limited space.

✅Solid Broshuis frame – considered one of the most durable on the market.

✅Possibility of extension by up to 5.5 meters – flexible adjustment to the transported loads.

✅Optimal loading height allows for the transport of high loads without exceeding height limits.

IDEAL FOR TRANSPORTING:

?yachts and boats

?construction and agricultural machines (combines, excavators, tractors)

?steel structures and prefabricated elements

?large tanks, silos, industrial modules

BROSHUIS – A BRAND WITH TRADITION

Broshuis is a leader in the field of specialist low-bed semi-trailers, known for its exceptional attention to quality, innovation and safety. The products of this Dutch brand have been a standard in oversized transport worldwide for years.

?Location: Poland

?Possibility of issuing a VAT invoice

✅Available immediately - ready to work after a full technical inspection
